Magnification:3× - 24×
Palettes:Black Hot, White Hot, Red Hot, Fusion
Reticle:5 types, 4 colors, on/off
Boresight Adjustment:Digital Controlled
Boresight Increment:0.13 mil / 0.44 MOA
Distance Measurement
Yes (Stadiametric):Scene Mode
Jungle, Recognition:Picture In Picture Mode (PIP)
Yes:Video Recording
Yes:Defective Pixels Correction (DPC)
Yes:Uniformity Correction
Auto, Manual, External Correction:Digital Magnification
Detector type:12μm, Uncooled, 50 Hz, < 35 mK (25°C, F# = 1.0)
Standby Mode:Yes
Resolution:384 × 288
Detection Range (6' object):1800 m/yd
Snapshot:Yes
Lens system:35 mm; F/1.0
Field of view (H × X):7.5° × 5.6°
Digital zoom:1×, 2×, 4×, 8×
Diopter adjustment range:-5 to +5 dpt
Eye relief:≥ 60 mm
Display:1024×768, 50 Hz, OLED
Storage:64 GB EMMC
Battery Type:Two 18650 Rechargeable Batteries (built-in) and one CR123 Battery
Wi-Fi:Yes
CVBS Output:Yes (via USB)
Battery Life (Operating):Up to 15 hr
Power supply:5 VDC/2 A, USB Type-C Supports QC3.0
Operating Temperature Range:-30°C to +55°C (-22°F to +131°F)
Degree of Protection:IP67
Weight:890 g ( 1.96 lb)
Overall Dimensions:407 × 78× 76 mm (16.0 × 3.1 × 3.0 in)
